HikMicro Lynx LH25 2.0 Thermal Monocular
HikMicro Lynx LH25 2.0 Thermal Monocular
Thermal Resolution: 384x288
Thermal Lens: 25mm/f1.0
Detection Distance: 1200m
Free Insured Shipping
Includes Product Lifetime Support
Couldn't load pickup availability
The HikMicro Lynx LH25 2.0 is the pinnacle of handheld thermal technology. This flagship model in the Lynx 2.0 series boasts a 384×288 resolution and NETD of <20 mK, ensuring sharp, detailed imaging. Its 25 mm thermal lens, optimized for short to medium-range detection, can identify targets up to 1200 meters away, making it ideal for a wide range of applications. The LH25 2.0 introduces a replaceable battery system, enhancing field usability with up to 6.5 hours of continuous operation. Embrace the advanced capabilities of the Lynx LH25 2.0, the flagship of the Lynx 2.0 series, available at Cape Thermal. Elevate your thermal observation with this top-tier monocular, designed for those who demand the best.
HikMicro Lynx LH25 2.0 Thermal Monocular Key Features:
- High-Resolution Imaging: 384x288 thermal resolution captures every detail.
- Exceptional Sensitivity: NETD <20 mK for clear imaging in various conditions.
- Extended Detection Range: Identify heat signatures up to 1200 meters away.
- Replaceable Battery System: Ensures prolonged use in the field.
- Lightweight Design: At just 275g, it's built for ease of use and portability.
- OLED Display: The 1024×768 screen offers crisp, vibrant visuals.
Lynx LH25 2.0 Thermal Monocular 360° view:
More Lynx LH25 2.0 Thermal Imaging Monocular Information:
Share


















HikMicro Lynx LH25 2.0 Thermal Monocular Detection, Recognition, & Identification Ranges
Detection, recognition, and identification ranges are approximate and based on ideal conditions.
-
Bush Pig - 100cm
Detection: 1200m
Recognition: 320m
Identification: 150m -
Deer - 150cm
Detection: 2000m
Recognition: 500m
Identification: 250m -
Elephant - 300cm
Detection: 4050m
Recognition: 1000m
Identification: 500m
HikMicro Lynx LH25 2.0 Thermal Monocular Detailed Specifications
Thermal Module Specifications
Resolution: 384x288
Lens: 25mm/f1.0
NETD: <20mK
Pixel Interval: 12μm
Response Waveband: 8-14μm
Frame Rate: 50Hz
Zoom: 2.4x to 19.2x (8x)
Focus Mode: Focus Ring
Display
Screen: 1024x768 OLED
Field of View: 10.5° × 7.9° / 18.4 × 13.8 m (HxV) @ 100m
Palettes: Black Hot, White Hot, Red Hot, Fusion
System Functions
Storage: 16Gb Built-in
Notable features: Wi-Fi
HikMicro Sight Smartphone App
Records photos & videos
Picture-in-Picture Mode
Hotspot Tracking
Distance Measurement
20mm Exit Pupil with 6mm Eye Relief
CVBS
Battery & Power
Battery Life: 6.5 hours: CVBS and hotspot off.
Power Supply: DC 5V 2A USB-C (Supports Power Bank)
Battery Type: Replaceable and Rechargeable Lithium Battery
General
Operating Temperature: -30°C to 55°C
Ingress Protection: IP67
Dimensions: 164 × 56 × 60.8 mm (277g)
SKU: HM-TS83-25S1GW-LH25 2.0
Package Contents
Quick Start Guide
Non-Dust Cloth
Usb-cable
Protective Bag
Wrist Strap
External Charger
2 x Batteries
