HikMicro Lynx LH25 2.0 Thermal Monocular

HikMicro Lynx LH25 2.0 Thermal Monocular

  • Thermal Resolution: 384x288
  • Thermal Lens: 25mm/f1.0
  • Detection Distance: 1200m

  • Free Insured Shipping
  • Includes Product Lifetime Support
Regular price R 32,399.00 ZAR
Regular price Sale price R 32,399.00 ZAR
Sale Sold out
Shipping calculated at checkout.

The HikMicro Lynx LH25 2.0 is the pinnacle of handheld thermal technology. This flagship model in the Lynx 2.0 series boasts a 384×288 resolution and NETD of <20 mK, ensuring sharp, detailed imaging. Its 25 mm thermal lens, optimized for short to medium-range detection, can identify targets up to 1200 meters away, making it ideal for a wide range of applications. The LH25 2.0 introduces a replaceable battery system, enhancing field usability with up to 6.5 hours of continuous operation. Embrace the advanced capabilities of the Lynx LH25 2.0, the flagship of the Lynx 2.0 series, available at Cape Thermal. Elevate your thermal observation with this top-tier monocular, designed for those who demand the best.

HikMicro Lynx LH25 2.0 Thermal Monocular Key Features:

  • High-Resolution Imaging: 384x288 thermal resolution captures every detail.
  • Exceptional Sensitivity: NETD <20 mK for clear imaging in various conditions.
  • Extended Detection Range: Identify heat signatures up to 1200 meters away.
  • Replaceable Battery System: Ensures prolonged use in the field.
  • Lightweight Design: At just 275g, it's built for ease of use and portability.
  • OLED Display: The 1024×768 screen offers crisp, vibrant visuals.

Lynx LH25 2.0 Thermal Monocular 360° view:

More Lynx LH25 2.0 Thermal Imaging Monocular Information:

View full details

HikMicro Lynx LH25 2.0 Thermal Monocular Detection, Recognition, & Identification Ranges

Detection, recognition, and identification ranges are approximate and based on ideal conditions.

  • Thermal image of a group of pigs, likely Kunekune pigs, taken with a HikMicro Condor CQ50L Thermal Monocular. Their heat signatures are visible in shades of orange and yellow against a cool purple background.

    Bush Pig - 100cm

    Detection: 1200m

    Recognition: 320m
    Identification: 150m

  • Thermal image of a deer standing in a field, showcasing the detail and clarity of the Pulsar Axion 2 XQ35 Pro thermal monocular.

    Deer - 150cm

    Detection: 2000m

    Recognition: 500m
    Identification: 250m

  • HikMicro Condor CQ50L captures stunning thermal image of elephants drinking at a watering hole in the African savanna. The high-resolution thermal monocular reveals intricate details of their heat signatures, even in low-light conditions.

    Elephant - 300cm

    Detection: 4050m

    Recognition: 1000m
    Identification: 500m

1 of 3

HikMicro Lynx LH25 2.0 Thermal Monocular Detailed Specifications

Thermal Module Specifications

Resolution: 384x288

Lens: 25mm/f1.0

NETD: <20mK

Pixel Interval: 12μm

Response Waveband: 8-14μm

Frame Rate: 50Hz

Zoom: 2.4x to 19.2x (8x)

Focus Mode: Focus Ring

Display

Screen: 1024x768 OLED

Field of View: 10.5° × 7.9° / 18.4 × 13.8 m (HxV) @ 100m

Palettes: Black Hot, White Hot, Red Hot, Fusion

System Functions

Storage: 16Gb Built-in

Notable features: Wi-Fi
HikMicro Sight Smartphone App
Records photos & videos
Picture-in-Picture Mode
Hotspot Tracking
Distance Measurement
20mm Exit Pupil with 6mm Eye Relief
CVBS

Battery & Power

Battery Life: 6.5 hours: CVBS and hotspot off.

Power Supply: DC 5V 2A USB-C (Supports Power Bank)

Battery Type: Replaceable and Rechargeable Lithium Battery

General

Operating Temperature: -30°C to 55°C

Ingress Protection: IP67

Dimensions: 164 × 56 × 60.8 mm (277g)

SKU: HM-TS83-25S1GW-LH25 2.0

Package Contents

Quick Start Guide
Non-Dust Cloth
Usb-cable
Protective Bag
Wrist Strap
External Charger
2 x Batteries
