Pulsar AXION Series - Thermal handheld monoculars with LRF

Pulsar Axion thermal monoculars are the ultimate tools for outdoor enthusiasts, hunters, and adventurers seeking to elevate their nighttime experiences. Engineered with cutting-edge technology and built for rugged durability, Axion monoculars redefine what's possible in low-light and complete darkness. Explore Pulsar Africa

Unveil the Unseen with Pulsar AXION

High-Performance Thermal Imaging: The Axion series boasts state-of-the-art thermal sensors that effortlessly detect heat signatures, revealing animals, people, and objects concealed by darkness or challenging conditions like fog or rain. Experience the thrill of spotting wildlife unseen by the naked eye, track your prey with precision, or simply navigate your surroundings with confidence.

Thermal Monocular's and their Benefits.

Farmers, protect your livestock and valuable assets from nocturnal predators with thermal monoculars. Easily detect jackals, caracals, and other threats lurking in the darkness, allowing for swift and effective intervention. Safeguard your farm and livelihood with the power of thermal vision. Nature Conservation aided by thermal monoculars/ imagers.

Explore the Lynx Series

Thermal Monocular Spotlight

Pulsar Telos - Handheld Thermal devices

Pulsar Telos Series

Pulsar Telos is an upgradable Thermal Monocular. Telos is a new concept of upgradeable thermal monoculars by Pulsar Africa. It is the first line of thermal devices on the market to offer the option of technical hardware upgrade.

Hikmicro CONDOR Series

Hikmicro CONDOR Series is the epitome of thermal imaging technology by Hikmicro. Tailored for professionals and enthusiasts alike, this thermal monocular with rangefinder is a quintessential tool for security, surveillance, and hunting.

Infiray AFFO Series

Detailed information about the InfiRay AFFO Series Handheld Thermal Monocular Collection.

Important Links:

Care Tips for your InfiRay Thermal Vision Monocular:

  • Do not aim the thermal imaging camera at direct sunlight or other high-intensity radiation sources outside of the manufacturer specified temperature operation range
  • Do not touch or damage the thermal camera detector window and lens
  • Do not allow thermal imaging camera to come in to contact with water
  • Do not attempt to use solvents or chemicals to clean the thermal camera
  • Please ensure that any USB or third party connections are done in accordance with the manufacturer power specifications
  • Prevent static electricity
  • Do not disassemble thermal camera as this will void the warranty

If you are having problems with your device, please mail us: support@capethermal.com

InfiRay AFFO Series Handheld Thermal Vision Monocular for Sale from Cape Thermal

InfiRay AFFO Series Handheld Thermal Vision Monocular - Key Features and specifications:

  • High performance 12µm uncooled Vox thermal imaging sensor
  • Ergonomic and compact design
  • HDMI Interface to transmit audio and video to compatible devices
  • Additional practical functions such as picture-in-picture and stadiametric rangefinder
  • Wider detection and operating temperature ranges with hot target highlighting
  • Multiple colour palettes for different display scenarios
  • Upgraded IP167 ingress protection
  • Upgraded lens cap protection
  • 32Gb built-in memory
  • View on Cape Thermal Store: AP13 | AL19 | AL25





InfiRay AFFO Series Thermal Imaging Monocular for Sale with Cape Thermal

InfiRay AFFO Series Handheld Thermal Monocular Detailed specifications:

*DRI is calculated using the Johnson Criteria. Calculations applied in a vacuum and do not take any environmental or other factors in to account.

AP13 AL19 AL25
Buy it from Cape Thermal Click here Click here Click here
Thermal Resolution (Pixels) 256x192 384x288 384x288
Pixel Size (μm) 12 12 12
NETD (mK) ≤40 ≤40 ≤40
Frame Rate (Hz) 25 50 50
Objective Lens (mm) 13 19 25
F.O.V (field of view°) 13.5 x 10.1 13.8 x 10.4 10.5 x 7.9
Digital Zoom (X) 1 / 2 1 / 2 / 4 1 / 2 / 4
Diopter Adjustment -3 ~ +1 -7 ~ +2 -7 ~ +2
Display Type LCOS OLED OLED
Display Resolution (Pixels) 720x540 640x400 640x400
Built-in Battery Type 3.6Ah Li-Ion 3.6Ah Li-Ion 3.6Ah Li-Ion
Operating Hours ±9 ±7 ±7
External Power Supply Type USB type-C USB type-C USB type-C
External Power Supply Voltage 5V 5V 5V
Ingress Protection Rating IP67 IP67 IP67
Built-in Memory (Gb) 32 32 32
Operating Temperature (°C) -10 ~ +50 -20 ~ +50 -20 ~ +50
Dimensions (mm) 160x60x60 169x60x60 169x60x60
Weight (g) <340 <350 <350
Android App Google Play Download Google Play Download Google Play Download
iOS App Apple App Store Download Apple App Store Download Apple App Store Download
Detection Distance - Human size @ 1.7x0.5m (m)* 600 850 1100
Recognition Distance - Human size @ 1.7x0.5m (m)* 150 220 290
Identification - Human size @ 1.7x0.5m (m)* 76 110 140
