HIKMICRO Habrok 4K HE25L 2.0 Multispectral Binocular
- Thermal Resolution: 256x192
- Thermal Lens: 25mm
- Pixel Interval: 12µm
- NETD: < 18mK
- Thermal FOV: 7.0 x 5.3°
Couldn't load pickup availability
Detection Range
Key Features & Highlights
Product Overview
The HIKMICRO Habrok 4K HE25L 2.0 is an innovative all-in-one multispectral binocular designed specifically for superior daytime and nighttime performance. By combining a high-sensitivity 256 thermal detector with an advanced 4K digital optical sensor, this unit eliminates the need to carry separate devices for scouting and identification. Whether used for forest and field hunting, birding, or search and rescue, the HE25L 2.0 provides a comprehensive "Multispectral" viewing experience that standard thermal binoculars cannot match.
Equipped with a 1000m Laser Rangefinder (LRF) and replaceable IR illuminators (940nm and 850nm), the Habrok 4K 2.0 ensures precision in all weather conditions. Its compact, ergonomic design weighs only 895g, making it comfortable for extended adventuring. Featuring the HIKMICRO Shutterless Image System (HSIS), the device provides a smooth, uninterrupted visual feed across both its thermal and 4K digital channels.
Advanced Multispectral Performance
The standout feature of the HE25L 2.0 is its ability to merge the worlds of thermal detection and high-definition optical clarity. While the thermal sensor excels at picking up heat signatures at distances up to 1200m, the 4K digital sensor provides the necessary detail for positive target identification. This dual-sensor approach ensures that you never miss a heat source and always have the resolution required to see exactly what you are looking at.
Unmatched Image Quality and Sensitivity
With a professional-grade NETD < 18 mK, the thermal module can detect the most minute temperature differences, even in challenging environments like thick fog or heavy rain. On the optical side, the 60mm F2.2 digital lens provides a massive 5.5x to 22x magnification range, ensuring sharp, full-color imagery during the day and clear digital night vision after dark.
Free Shipping
Full Transit Insurance. Your investment is protected.
5 Star Google Rating
Experience the Cape Thermal Difference.
24/7 Support
Talk to us anytime via Whatsapp or phone.
Authorized Partner
Official brand partner for all top brands.
Technical Specifications
While we strive for absolute accuracy, manufacturer specifications and hardware configurations are subject to change without prior notice. For mission-critical applications, we recommend consulting our team to verify current technical data.
Thermal Specifications
| Sensor Type | VOx Uncooled Focal Plane Arrays (Thermal) / 4K Progressive Scan CMOS (Digital) |
| Thermal Resolution | 256x192 |
| Pixel Pitch | 12 µm |
| NETD | < 18 mK |
| Thermal Lens | 25 mm |
| Focal Ratio (Aperture) | F1.0 |
| Field of View | 7.0 x 5.3 |
| Magnification | Digital: 5.5x – 22.0x / Thermal: 4.3x – 17.2x |
| Spatial Resolution | 0.48 mrad (Digital) / 3.75 mrad (Thermal) |
| Min. Focusing Distance | Thermal: 3m / Digital: 8m |
| Focus Mode | Rear Focus Wheel |
| Frame Rate | 50 Hz |
| Spectral Range | 7.5 µm to 14 µm |
| Detection Range (1.7m Subject) | 1200 m |
Optical & Night Vision
| Optical Sensor | 1.88'' Progressive Scan CMOS |
| Optical Resolution | 3840x2160 (4K Ultra HD) |
| Optical Lens | 60 |
| Optical Focal Ratio | F2.2 |
| Min. Illumination | 0.001 Lux (F2.2, White and Black) |
| IR Wavelength | 850 nm and 940 nm |
| IR Emitter Type | LED (Replaceable 850nm and 940nm IR Illuminators) |
| IR Beam Angle | Adjustable (Adjustable Beam Angle for IR Illuminator) |
| Smart IR Technology | Yes |
| Night Viewing Range | 400 m |
| Interpupillary Range | 60 mm to 74 mm |
Precision, Optics & Lasers
| LRF Safety Class | Class 1 |
| LRF Wavelength | 905nm |
| LRF Max Range | 1000 m |
| LRF Min Range | 10 m |
| LRF Accuracy | +/- 1 m |
| Measurement Overlays | Distance (LRF), GPS Coordinates, Magnetic Compass Direction |
| Environmental Calibration | Auto, Manual, External Correction |
Thermography & Measurement
| Distance to Spot Ratio | 0.48 mrad (Digital) / 3.75 mrad (Thermal) |
System & Display
| Display Info | 0.49 inch OLED, 1920x1080 resolution with Day, Night, Thermal, and Fusion modes |
| Screen Brightness | Yes |
| Screen Contrast | Yes |
| Digital Zoom | 1x, 2x, 4x, 8x |
| Color Palettes | Black Hot, White Hot, Red Hot, Fusion, Optical: Day, Night, Auto, Green, Yellow |
| Image Enhancement | HIKMICRO Shutterless Image System (HSIS), Digital Detail Enhancement (DDE) |
| Flat Field Correction | Auto, Manual, External Correction |
| Image Modes | Day, Night, Thermal, Fusion |
| Eye Pupil | 6 |
| Eye Relief | 15 |
| Diopter Range | -5 D to +3 D |
| Storage Capacity | Built-in 64 GB EMMC |
| Media Capacity | 64 |
| Media Format | JPEG, MP4 |
| Recording Capabilities | Video Recording, Audio Recording |
| Built-In Microphone | Yes |
| Battery Type | Replaceable and Rechargeable Li-ion Battery (x4 included) |
| Battery Life | ≥6.5 |
| Power Supply | 5V DC/2A, USB Type-C |
| Power Saving Features | Yes (Proximity Sensor for auto-screen off) |
| Battery Indicator HUD | Yes |
| Polarity Protection | Yes |
| Overvoltage Protection | Yes |
Connectivity & Software
| Wi-Fi Hotspot | Supported |
| USB Connectivity | USB Type-C |
| GPS Positioning | Yes |
| Digital Compass | Yes |
| Supported OS | iOS, Android |
| Software & Analysis | Hikmicro Sight App |
| Multilingual Support | Yes |
| Android App | Download App |
| iOS App | Download App |
Physical & Environmental
| Protection Level (IP Rating) | IP67 |
| Drop Test Rating | 1m |
| Operating Temperature | -30°C to +55°C |
| Storage Temperature | -30°C to +60°C |
| Relative Humidity | 10%–95% (non-condensing) |
| Dimensions & Weight | 143.1 x 74.8 x 223.3 mm / 895g |
| Tripod Mounting | UNC 1/4-20 interface for tripod (Adapter included) |
| Safety Certifications | RoHS / WEEE |
| EMC Certifications | CE / FCC |
| Other Hardware Features | HIKMICRO Shutterless Image System (HSIS), Replaceable IR Illuminators |
What's in the Box
| Box Contents | Hikmicro 4K HE25L 2.0 Multispectral Binocular Neck Strap Type-C Cable Tripod Adapter 4x Batteries Replaceable IR Illuminator OSG Lint-free Cloth Battery Charger |
