Raythink CX200 SE+ Handheld Thermography Camera
- Thermal Resolution: 256x192
- Thermal Lens: 3.2mm
- Pixel Interval: 12µm
- NETD: < 40mK
- Thermal FOV: 56×42°
Couldn't load pickup availability
Key Features & Highlights
Product Overview
The Raythink CX200 SE+ is a professional-grade handheld thermal camera designed for high-precision diagnostic work across various industrial sectors. This completely upgraded model features a self-developed 12μm256x192 uncooled infrared detector, making it a powerhouse for electrical maintenance, equipment inspection, and HVAC leak detection. By utilizing innovative AI real-time super-resolution technology, the CX200 SE+ upscales its native resolution to 320x240, providing technicians with significantly clearer and sharper infrared images.
Engineered for efficiency in the field, the Raythink CX200 SE+ boasts an ultra-fast startup duration of just 6 seconds, ensuring you can begin home inspections or power maintenance tasks without delay. Its rugged design is built to withstand harsh environments, featuring an IP54 waterproof and dustproof rating and 2-meter drop protection. Whether you are troubleshooting complex systems or performing routine circuit board repairing, the 15-hour battery life and built-in 32GB memory ensure that the CX200 SE+ remains productive throughout the entire workday.
Free Shipping
Full Transit Insurance. Your investment is protected.
5 Star Google Rating
Experience the Cape Thermal Difference.
24/7 Support
Talk to us anytime via Whatsapp or phone.
Authorized Partner
Official brand partner for all top brands.
Proven in the Field by Africa’s Top Observers
We don't just sell thermal gear; we specialize in it. The community relies on Cape Thermal for optics that endure the bush.
Swipe to read more →"My experience with them was great. They they where professional. They inquired about my situation and use to specifically recommend a product. They helped all along the way from the purchase to install. Even following up afterwards to see if I was happy. Will definitely recommend. Huge shout-out to Keegan."
"I received exceptional advice and service from Chris and Keegan from Cape Thermal!!!! I will strongly advise anyone to phone Cape Thermal 1st if they are in the market for thermal or nigt vision devices."
"I can only say: 10/10!!! The service was great, got the product I bought in time. I ordered the product online, no hassles at all. Good quality product as well. After sales is excellent, Keegan made sure we know how to use the product. I will definitely shop here again. I do recommend Cape Thermal as a good shopping shop."
Technical Specifications
While we strive for absolute accuracy, manufacturer specifications and hardware configurations are subject to change without prior notice. For mission-critical applications, we recommend consulting our team to verify current technical data.
Thermal Specifications
| Sensor Type | VOx Uncooled infrared detector |
| Thermal Resolution | 256x192 |
| Pixel Pitch | 12 µm |
| NETD | < 40 mK |
| Thermal Lens | 3.2 mm |
| Focal Ratio (Aperture) | F1.0 |
| Field of View | 56°×42 |
| Magnification | 1x, 2x, 4x Digital Zoom. |
| Spatial Resolution | 3.75mrad (IFOV) |
| Min. Focusing Distance | 0.3m |
| Focus Mode | Fixed focus |
| Frame Rate | 25 Hz |
| Spectral Range | 7.5 - 14μm |
Precision, Optics & Lasers
| Measurement Overlays | Central, Highest, and Lowest temperature point markers |
| Environmental Calibration | Supported via automatic switching of measurement modes. |
| Shock Resistance | 25g (IEC 60068-2-27) |
Thermography & Measurement
| Measurement Range | -20°C ~ +150°C, 100°C ~ +550°C |
| Temperature Accuracy | ±2°C or ±2% |
| Measurement Modes | Central, Highest, and Lowest temperature point tracking. |
| Level & Span Mode | Auto Temperature Width Stretch |
| Distance to Spot Ratio | 3.75mrad (IFOV) |
| Alarm Conditions | Highest/Lowest temp alarm (Full frame); Image pop-ups; Flash prompts |
| Alarm Indication | Highest/Lowest temperature alarm in full frame, image pop-ups, and flash prompts. |
| Annotations | Central, Highest, and Lowest temperature point tracking |
System & Display
| Digital Zoom | 4x |
| Color Palettes | 4 Color Palettes |
| Image Enhancement | AI Real-time Super-resolution (320x240); Intelligent image algorithm |
| Image Modes | Infrared |
| Defective Pixel Correction | Yes |
| Storage Capacity | Standard 32GB MicroSD, up to 128G |
| Media Capacity | Standard 32GB MicroSD, expandable up to 128GB |
| Media Format | Radiometric images, Radiometric Video |
| Recording Capabilities | Built-in Video and Image capture with radiometric temperature data |
| Battery Type | Built-in rechargeable lithium-ion battery |
| Battery Life | 15 |
| Power Supply | USB Type-C Charging |
| Power Saving Features | Auto shut-down setting |
Connectivity & Software
| Wi-Fi Hotspot | Not Supported |
| Video Streaming | Supports built-in video taking for local recording |
| USB Connectivity | USB Type-C |
| Supported OS | Windows (PC Infrared Analysis Software) |
| Software & Analysis | Professional PC Infrared Analysis Software for secondary analysis |
Physical & Environmental
| Protection Level (IP Rating) | IP54 |
| Drop Test Rating | 2m |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -20°C to +60°C |
| Relative Humidity | 10%–95% (non-condensing) |
| Vibration Resistance | 2.5g (IEC60068-2-6) |
| Dimensions & Weight | 231x75x92mm: 520g |
| Tripod Mounting | UNC 1/4-20 interface for tripod |
| Safety Certifications | CMA |
| EMC Certifications | CE/RoHS |
| Other Hardware Features | 6s Startup duration; AI real-time super-resolution (320x240) |
What's in the Box
| Box Contents | Raythink CX200 SE+Infrared camera USB cable 32GB SD card user manual storage bag certificate of qualification calibration certificate |
